- High brightness, scalable size Provides 5,200 lumens high-brightness display at up to 500"
- Premium display features Full HD, supports 4K input, edge-blending and geometric correction
- Unrestricted viewing Free from pixilation, glare, fingerprints and a central bevel
- Social distancing support Scalable display meets the needs of every audience configuration
- Plug, click and collaborate Collaborate using Epson’s wireless presentation system - ELPWP10
Technical Specification:
Technology:
- Projection System: 3LCD Technology, RGB liquid crystal shutter
- LCD Panel: 0.67 inch with C2 Fine
Image:
- Color Light Output: 5,200 Lumen- 3,640 Lumen (economy) In accordance with IDMS15.4
- White Light Output: 5,200 Lumen - 3,640 Lumen (economy) In accordance with ISO 21118:2020
- Resolution: WUXGA
- High Definition: Full HD
- Aspect Ratio: 16:10
- Contrast Ratio: 2,500,000 : 1
- Light source: Laser
- Laser Light source: 20,000 hours Durability High, 30,000 hours Durability Eco
- Keystone Correction: Manual vertical: ± 30 °, Manual horizontal ± 30 °
- Colour Video Processing: 10 Bits
- 2D Vertical Refresh Rate: 192 Hz - 240 Hz
- Colour Reproduction: Upto 1.07 billion colours
Optical:
- Throw Ratio: 1.35 - 2.20:1
- Zoom: Manual, Factor: 1 - 1.6
- Projection Lens Zoom Ratio: 1.35 - 2.2 : 1
- Lens: Optical
- Screen Size: 50 inches - 500 inches
- Projection Lens F Number: 1.5 - 1.7
- Projection Lens Focal Length: 20 mm - 31.8 mm
- Projection Lens Focus: Manual
- Offset: 27 : 1
Connectivity:
- Interfaces: RS-232C, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), Wireless LAN a/n (5GHz) (optional), VGA in (2x), VGA out, HDMI in (2x), HDBaseT, Miracast (optional), Jack plug out, Jack plug in (2x), USB 2.0-A, USB 2.0
- Epson iProjection App: Ad-Hoc / Infrastructure
Advanced Features:
- Security: Kensington lock, Padlock, Security cable hole, Wireless LAN unit lock
- 2D Colour Modes: Dynamic, Cinema, Presentation, sRGB, DICOM SIM
- Other features: A/V mute, Arc Correction, Built-in speaker, Easy OSD pre-setting, Edge Blending, Long light source life, PC Free, Quick Corner, Screen share, Source function, Ultra-wide display (16:6), iProjection App
- Video Color Modes: Cinema, Dynamic, Presentation, sRGB, DICOM SIM
- Projector control: via: AMX, Crestron, Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
General:
- Power consumption: 293 Watt, 223 Watt (economy), 0.3 Watt (standby), On mode power consumption as defined in JBMS-84 234 Watt
- Supply Voltage: AC 100 V - 240 V, 50 Hz - 60 Hz
- Product dimensions: 440 x 122 x 304 mm (Width x Depth x Height)
- Product weight: 7.7 kg
- Noise Level: Normal: 31 dB (A) - Economy: 23 dB (A)
- Supported Temperature: Storage -10° C - 60° C
- Supported Humidity: Operation 20% - 80%, Storage 10% - 90%
- Included Software: EasyMP Multi PC Projection
- Options: Air filter, Ceiling mount, Document camera, External Speaker, HDBaseT Transmitter, Safety wire set, Suspension adapter, WP System - ELPWP10, Wireless LAN unit, Wireless transmitter - ELPWT01
- Loudspeaker: 10 Watt
- What's in the box: Power cable, Remote control incl. batteries, User guide, Warranty Documents
- Room Type / Application: Boardroom, Home Cinema, Home Office, Large Meeting Room / Auditorium, Meeting room / Classroom, Signage / Retail, Visitor Attraction
- Positioning: Ceiling Mounted, Desktop, Floor, Wall Mounted
- Colour: White
