- 4K PRO-UHD for crisp, clear images 4K-enhanced, Full HD, UHD BD and HDR support
- Smooth, fast-moving action Frame interpolation and Detail Enhancement
- Watch a movie a day for 7 years 5,000 hours lamp life in Eco mode
- Fully motorised optics Powered zoom, focus and lens shift
- Wide lens shift Vertical ±96.3% and horizontal ±47.1%
Technical Specification:
Technology:
- Projection System: 3LCD Technology, RGB liquid crystal shutter
- LCD Panel: 0.74 inch with MLA (D9)
Image:
- Color Light Output: 2,600 Lumen In accordance with IDMS15.4
- White Light Output: 2,600 Lumen In accordance with ISO 21118:2020
- Resolution: 4K PRO-UHD
- High Definition: 4K enhancement
- Aspect Ratio: 16:9
- Contrast Ratio: 1,200,000 : 1
- Light source: Lamp
- Lamp: UHE, 250 W, 3,500 h durability, 5,000 h durability (economy mode)
- Keystone Correction: Manual vertical: ± 30 °
- Colour Video Processing: 10 Bits
- 2D/3D Frequency Image: 240 Hz / 480 Hz
- 2D Vertical Refresh Rate: 192 Hz - 240 Hz
- 3D Vertical Refresh Rate: 400 Hz - 480 Hz
- Colour Reproduction: Upto 1.07 billion colours
- HDR support: HDR10, HLG
Image:
- Throw Ratio: 1.35 - 2.84:1
- Zoom: Motorized, Factor: 2.1
- Lens: Optical
- Lens Shift: Motorized - Vertical ± 96.3 %, horizontal ± 47.1 %
- Lens position memory: 10 positions
- Screen Size: 50 inches - 300 inches
- Projection Distance Wide/Tele: 3 m - 6.3 m ( 100 inch screen
- Projection Lens F Number: 2 - 3
- Projection Lens Focal Length: 22.5 mm - 46.7 mm
- Projection Lens Focus: Motorized
Connectivity:
- Interfaces: USB 2.0-A, USB 2.0 Type B (Service Only), RS-232C, WLAN (optional), Trigger out, VGA in, HDMI in (2x), HDMI (HDCP 2.2), Ethernet interface (100 Base-TX / 10 Base-T)
- Epson iProjection App: Ad-Hoc / Infrastructure
Advanced Features:
- Security: Kensington lock, Wireless LAN security
- 3D: Active
- 2D Colour Modes: Dynamic, Natural, Cinema, Digital Cinema, Bright Cinema
- 3D Colour Modes: 3D Dynamic, 3D Cinema
- 3D Supported formats: Side by side, Top and bottom
- Other features: 3D depth adjustment, 4K enhancement, DCI colour gamut, Epson Cinema Filter, Epson Super White, Frame interpolation, ISF certification, Lens position memory, Super resolution, Wireless LAN capable
- Video Color Modes: Cinema, Dynamic, Natural, Bright Cinema
- Projector control: via: AMX, Crestron, Control4
General:
- Power consumption: 355 Watt, 271 Watt (economy), 0.35 Watt (standby), On mode power consumption as defined in JBMS-84 314 Watt
- Supply Voltage: AC 100 V - 240 V, 50 Hz - 60 Hz
- Product dimensions: 520 x 450 x 193 mm (Width x Depth x Height)
- Product weight: 11.2 kg
- Noise Level: Normal: 31 dB (A) - Economy: 20 dB (A)
- Supported Temperature: Operation 5° C - 35° C, Storage -10° C - 60° C
- Included Software: EasyMP Multi PC Projection
- Options: MB22 ceiling mount, Wireless LAN unit
- What's in the box: HDMI Cable Clamp, Main unit, Power cable, Remote control with background light incl. batteries, User's Manual Set
- Room Type / Application: 4K Gaming, 4K Streaming, Home Cinema, Sports, TV & Box sets
- Positioning: Ceiling Mounted, Desktop
- Colour: Black
