- Any room, any size Bright, large-format display options up to 100"
- Send productivity soaring Easy-to-use interface, optional responsive touch and fast set up
- Versaitle collaboration Expand connectivity, through wireless, VC cameras and many others
- Exceptional reliability Maintenance-free laser technology for fit-and-forget peace of mind
Tech Specs:
Technology:
- Projection System: 3LCD Technology, RGB liquid crystal shutter
- LCD Panel: 0.59 inch with C2 Fine
Image:
- Color Light Output: 4,000 Lumen- 2,800 Lumen (economy) In accordance with IDMS15.4
- White Light Output: 4,000 Lumen - 2,800 Lumen (economy) In accordance with ISO 21118:2020
- Resolution: WXGA 2
- High Definition: HD ready
- Aspect Ratio: 16:10
- Contrast Ratio: 2,500,000 : 1
- Light source: Laser
- Laser Light source: 20,000 hours Durability High, 30,000 hours Durability Eco
- Keystone Correction: Manual vertical: ± 3 °, Manual horizontal ± 3 °
- Colour Video Processing:10 Bits
- 2D Vertical Refresh Rate: 100 Hz - 120 Hz
- Colour Reproduction: Upto 1.07 billion colours
Optical:
- Throw Ratio: 0.28 - 0.37:1
- Zoom: Digital, Factor: 1 - 1.35
- Lens: Optical
- Screen Size: 65 inches - 100 inches
- Projection Lens F Number: 1.6
- Projection Lens Focal Length: 3.7 mm
- Projection Lens Focus: Manual
- Offset: 6 : 1
Connectivity:
- Interfaces: USB 2.0-A (2x), USB 2.0 (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, Wi-Fi Direct, VGA in (2x), VGA out, HDMI in (3x), Miracast, Jack plug out, Jack plug in (3x), Microphone input, Finger-touch interface (optional), Sync. in, Sync. out, Multi-Touch interface (optional)
- Epson iProjection App: Ad-Hoc / Infrastructure
- Network Protocol: HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Advanced Features:
- Security: Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
- 2D Colour Modes: Dynamic, Cinema, Presentation, sRGB, Blackboard
- Other features
- A/V mute, Arc Correction, Auto Calibration, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Digital zoom, Direct Power on/off, Document Camera Compatible, Dual Pen Support, Easy OSD pre-setting, Email notification, Finger-touch support, Home Screen, Horizontal and vertical keystone correction, Image Shift, Instant on/off, Interactive, Interactive Home Screen, Interactive OSD menu, Mail notification function, Microphone input, Network administration, Network projection, OSD copy function, PC Interactive, PC free annotation, Projection App for Chromebook, Quick Corner, Schedule Function, Screen Mirroring, Screen share, Sliding split-screen feature, Split-Screen-Function, Super resolution, Web Control, Web Remote, Whiteboard sharing function, Wireless LAN capable, iProjection App, iProjecton set-up by QR code
- Interactivity: Yes - pen and finger-touch
- Video Color Modes: Blackboard, Cinema, Dynamic, Presentation, sRGB
- Projector control: via: AMX, Crestron, Extron, Crestron (RS-232c only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
General:
- Power consumption: 255 Watt, 197 Watt (economy), 0.5 Watt (standby), On mode power consumption as defined in JBMS-84 200 Watt
- Supply Voltage: AC 100 V - 240 V, 50 Hz - 60 Hz
- Product dimensions: 356 x 395 x 133 mm (Width x Depth x Height)
- Product weight: 5.8 kg
- Noise Level: Normal: 36 dB (A) - Economy: 26 dB (A)
- Supported Temperature: Storage -10° C - 60° C
- Included Software: Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projector Management
- Options: Connection and control box, Document camera, External Speaker, Pen tip(Felt), Pen tip(Teflon), Wall mount, Wireless LAN unit
- Loudspeaker: 16 Watt
- What's in the box: 2 x Pen tip(Teflon), 4 x Pen tip(Felt), Interactive pens, Pen Holder/Stand, Power cable, Quick Start Guide, Remote control incl. batteries, Removable battery x2, Replacement pen tips, USB cable
- Room Type / Application: Boardroom, Meeting room / Classroom
- Positioning: Ceiling Mounted, Table Mounted, Wall Mounted
- Colour: White
