- Any room, any size Bright, large-format display options up to 120"
- Every-angle viewing No restricted angles, shadows, glare or blind spots
- Multiple collaboration options Expand connectivity through BYOD devices, VC cameras and more
- Document camera compatibility Create a totally immersive experience with sound and visuals
- Exceptional reliability Maintenance-free laser technology for fit-and-forget peace of mind
Technical Specification:
Technology:
- Projection System: 3LCD Technology, RGB liquid crystal shutter
- LCD Panel: 0.59 inch with C2 Fine
Image:
- Color Light Output: 4,000 Lumen- 2,800 Lumen (economy) In accordance with IDMS15.4
- White Light Output: 4,000 Lumen - 2,800 Lumen (economy) In accordance with ISO 21118:2020
- Resolution: WXGA 2
- High Definition: HD ready
- Aspect Ratio: 16:10
- Contrast Ratio: 2,500,000 : 1
- Light source: Laser
- Laser Light source: 20,000 hours Durability High, 30,000 hours Durability Eco
- Keystone Correction: Manual vertical: ± 3 °, Manual horizontal ± 3 °
- Colour Video Processing: 10 Bits
- 2D Vertical Refresh Rate: 100 Hz - 120 Hz
- Colour Reproduction: Upto 1.07 billion colours
Optical:
- Throw Ratio: 0.28 - 0.37:1
- Zoom: Digital, Factor: 1 - 1.35
- Lens: Optical
- Screen Size: 65 inches - 120 inches
- Projection Lens F Number: 1.6
- Projection Lens Focal Length: 3.7 mm
- Projection Lens Focus: Manual
- Offset: 6 : 1
Connectivity:
- Interfaces: USB 2.0-A (2x), USB 2.0, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, Wi-Fi Direct, VGA in (2x), VGA out, HDMI in (3x), Miracast, Jack plug out, Jack plug in (3x), Microphone input
- Epson iProjection App: Ad-Hoc / Infrastructure
- Network Protocol: HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Advanced Features:
- Security: Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
- 2D Colour Modes: Dynamic, Cinema, Presentation, sRGB, Blackboard
- Other features: A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Digital zoom, Direct Power on/off, Document Camera Compatible, Easy OSD pre-setting, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, Instant on/off, Mail notification function, Microphone input, Network administration, Network projection, OSD copy function, Quick Corner, Schedule Function, Split-Screen-Function, Super resolution, Web Control, Web Remote, Wireless LAN capable
- Interactivity: No
- Video Color Modes: Blackboard, Cinema, Dynamic, Presentation, sRGB
- Projector control: via: AMX, Crestron, Extron, Crestron (RS-232c only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
General:
- Power consumption: 255 Watt, 197 Watt (economy), 0.5 Watt (standby), On mode power consumption as defined in JBMS-84 200 Watt
- Supply Voltage: AC 100 V - 240 V, 50 Hz - 60 Hz
- Product dimensions: 356 x 395 x 133 mm (Width x Depth x Height)
- Product weight: 5.7 kg
- Noise Level: Normal: 36 dB (A) - Economy: 26 dB (A)
- Supported Temperature: Storage -10° C - 60° C
- Included Software: EasyMP Multi PC Projection, Epson Projector Management
- Options: Connection and control box, Document camera, External Speaker, Wall mount, Wireless LAN unit
- Loudspeaker: 16 Watt
- What's in the box: Power cable, Quick Start Guide, Remote control incl. batteries, Removable battery x2
- Room Type / Application: Boardroom, Meeting room / Classroom
- Positioning: Ceiling Mounted, Table Mounted, Wall Mounted
- Colour: White
