Newly designed, A0 capable, web-connected ePrinter with breakthrough ease-of-use.

Features

Enjoy an innovative user experience.

Eliminate output clutter – get flat, collated prints thanks to the integrated outputstacking tray.
Gain full control – monitor media rolls, view printer status on the touchscreen, and trackjobs during printing.
Load paper rolls effortlessly, even when seated, with true front roll loading and automatic roll alignment.
Print up to A0/E with a compact, 914 mm (36-inch) printer designed with a flat surface for quick checking of your printouts.

Get fast and quality prints from the very first time.

Print fast: create professional A1 prints in 21 seconds, and collate jobs with the output stacking tray.
Complete your work efficiently by printing correctly from the outset, thanks to true print previews.
Get dark blacks, true neutral greys and vivid colours with six Original HP inks and the HP printhead.
Process complex files easily with up to 32 GB of virtual memory, HP-GL/2, and PDF support2 for most OS.

Print from virtually anywhere.

Use your Apple® or Android™ smartphone or tablet to print from virtually anywhere.
Access and print projects from the cloud when you're out of the office, using HP Designjet ePrint & Share.
Automatically save copies of your projects to the cloud when you print using HP Designjet ePrint & Share.
Print without drivers using a USB stick or directly email projects to your HP Designjet T920 ePrinter.

Specifications

Print

Line DrawingsL: 21 sec/page, 120 A1 prints per hour
Print resolution: Up to 2400 x 1200 optimised dpi from 1200 x 1200 input dpi and Optimisation For Photo Paper selected
Margins (top x bottom x left x right): Roll: 5 x 5 x 5 x 5 mm ; Sheet: 5 x 22 x 5 x 5 mm
Technology: HP Thermal Inkjet
Ink types: Dye-based (C, G, M, pK, Y); pigment-based (mK)
Ink colours: 6 (1 each cyan, grey, magenta, matte black, photo black, yellow)
Ink drop: 6 pl (C, M, Y, G, pK); 9 pl (mK)
Print cartridge volume delivered: HP 727 Ink Cartridge: cyan, grey, magenta, matte black, photo black, yellow (130 ml); matte black (69 ml); cyan, grey, magenta, photo black, yellow (40 ml)
Print head nozzles: 9632
Print heads: 1 (cyan, grey, magenta, matte black, photo black, yellow)
Line accuracy: +/- 0.1%
Line accuracy note: +/- 0.1% of the specified vector length or +/- 0.2 mm
(whichever greater) at 23ºC (73ºF), 50-60% relative humidity, on A0/E HP Matte. Film in Best or Normal mode with Original HP inks
Minimum line width: 0.02 mm (HP-GL/2 addressable)
Guaranteed minimum line width: 0.07 mm (ISO/IEC 13660:2001(E))
Maximum print length: 91 m
Maximum print weight: 11.9 kg
Maximum optical density: 6 L* min/2.15

Media

Handling Input: automatic front-loading roll feed; sheet feed; Output: integrated output stacking tray (from A4 to AO, with up to 50 A1-size capacity); basket; automatic cutter.
Types: Bond and coated paper (bond, coated, heavyweight coated, super heavyweight plus matte, coloured), technical paper (natural tracing, translucent bond, vellum), film (clear, matte, polyester), photographic paper (satin, gloss, semi-gloss, matte, high-gloss), backlit, self-adhesive (two-view cling, indoor paper, polypropylene, vinyl)
Weight: 60 to 328 g/m²
Size: 210 x 279 to 914 x 1219 mm
Thickness: Up to 0.5 mm (up to 0.6 mm printed to the output stacking tray with manual mode)

Memory

Memory Standard: 32 GB virtual memory
Hard disk: 320 GB and front panel job queues available only for CR355A.

Connectivity

Interfaces (standard): Gigabit Ethernet (1000Base-T) (includes an embedded Jetdirect print server)

Print languages (standard)

CR354A: HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, HP PCL 3 GUI, URF
CR355A: Adobe® PostScript® 3, Adobe PDF 1.7 Extension Level 3, HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, HP PCL 3 GUI, URF
CR355B: Adobe PostScript 3, Adobe PDF 1.7 Extension Level 3, HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, HP PCL 3 GUI, URF

Drivers included

CR354A: HP-GL/2, HP-RTL drivers for Windows; HP PCL 3 GUI driver for Mac OS X
CR355A: HP-GL/2, HP-RTL drivers for Windows; PostScript Windows, Linux, and Mac drivers
CR355B: HP-GL/2, HP-RTL drivers for Windows; PostScript Windows, Linux, and Macdrivers

Dimensions (w x d x h)

Printer : 399 x 916 x 1110 mm
Packaged: 1502 x 759 x 775 mm

Weight

Printer: 87 kg
Packaged: 112.5 kg
